Efficiently evaluate spherical aberration across complete optical systems
Understanding spherical aberration behavior across all system configurations, wavelengths, and field points is essential for achieving high image quality and optical performance.
Advanced Spherical Aberration Analysis streamlines this evaluation by systematically calculating spherical aberration values — providing clear insights for both design validation and system improvement.
Key Features:
- Comprehensive Analysis: Calculates spherical aberration for each configuration, wavelength, and field point of the optical system.
- High Precision Output: Spherical aberration values are expressed in milliwaves (mλ) for accurate and meaningful interpretation.
- Graphical Visualization: Intuitive plots reveal spherical aberration trends and system characteristics.
- Data Export: All calculated values are saved into structured text files for further analysis and documentation.
- Seamless Workflow Integration: Results are also summarized directly in the MATLAB command window for quick inspection.
With Advanced Spherical Aberration Analysis, optical engineers and designers can explore spherical aberration in greater detail, enabling better-informed design choices and enhanced optical system performance.
Looking for additional functionality? We offer free customization. Whether you need specific plots, analysis features, or other enhancements, we’ll tailor this tool to your requirements—at no extra development cost.
Tool Features
| Feature | Description |
|---|---|
| Simulation Types | Zernike spherical aberration Seidel spherical aberration Users can enable or disable each simulation type individually, allowing full customization of the analysis process. |
| Output Figures | Zernike Spherical Aberration vs. Wavelength Across Field Points Zernike Spherical Aberration vs. Field Across Wavelengths Maximum Zernike Spherical Aberration vs. Configuration Zernike Spherical Aberration vs. Field Across Wavelengths Zernike Spherical Aberration vs. Wavelength Across Field Points Zernike Spherical Aberration vs. Configuration Across Wavelengths Zernike Spherical Aberration vs. Configuration Across Fields Maximum Seidel Spherical Aberration vs. Configuration Seidel Spherical Aberration vs. Wavelength Seidel Spherical Aberration vs. Wavelength Across Configurations Seidel Spherical Aberration vs. Surface Number Across Wavelengths Seidel Spherical Aberration vs. Wavelength Across Surfaces Seidel Spherical Aberration vs. Configuration Across Wavelengths Seidel Spherical Aberration vs. Wavelength Across Configurations |
| Export Formats | MATLAB Formats: FIG, M, MFIG Standard Images: JPEG, PNG, TIFF, TIFFN, BMPMONO, BMP, BMP16M, BMP256 Vector Graphics: META Scientific & Data Formats: HDF, PBM, PBMRAW, PGM, PGMRAW, PPM, PPMRAW, PCXMONO, PCX24B, PCX256, PCX16 Users can enable or disable each output format individually, allowing full customization of the export process. |
| LICENSE | |
| Availibility | Immediate |
| License Model | Annual Lease |
| Support | Included during lease term 24/7, 365-day support |
| Updates | Included during lease term |
| Installation Support | Yes |
| Compatible Versions | - All Zemax OpticStudio versions - All Ansys Zemax OpticStudio versions |
| Connection Mode | - Standalone Application - Interactive Extension is is available upon request. |
| Price | $2,400 USD per seat / year (+ tax) |
| Discounts | For multiple licenses purchased, increasing discounts apply to all seats: 10% off for 2–3 licenses, 15% off for 4–5, 20% off for 6–7, 25% off for 8–9, and 30% off for 10 or more. |
| Payment Terms | 30-day free trial, followed by immediate payment via Stripe for annual lease |
| Payment Methods | Stripe (credit/debit cards, online payments only) |
